FEATURES

• 2x DDR4 2400/2666Hz SODIMM. Max. up to 64GB
• Triple Independent Display by 1x DVI-I and 2x DisplayPort
• 2x Intel® GbE supporting Wake-on-LAN and PXE
• 2x Full-size mini PCIe for communication or expansion modules, 2x SIM socket
• 4x 2.5” SATA HDD Bay and 1x mSATA with RAID 0, 1, 5, 10 support
• 1x M.2 (M Key, NVMe PCIe x4, 2280); 1x M.2 (E Key, PCIe x2, 2230, USB 2.0, Support CNVi)
• 6x RS-232/422/485 (w/ 2x internal), 4x USB 3.2 Gen 2, 5x USB 3.2 Gen 1
• 8x DI + 8x DO with isolation
• 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
• Wide Operating Temperature -25°C to 70°C (35W CPU); -25°C to 60°C (65W CPU)
• TPM 2.0 Supported
