FEATURES

• Support 12/13/14th Gen Intel® RPL S / ADL Processor (LGA 1200, 35W TDP)
• Intel® Q670 Express Chipset
• 4x Independent Displays by 4x DisplayPort
• 2x Intel® GbE supporting Wake-on-LAN and PXE
• 3x External SIM socket
• 2x 2.5″ SATA HDD Bay (1x Internal) and 1x mSATA, with RAID 0, 1, 5 support
• 1x M.2 (E Key, PCIe x1, USB 2.0, 2230)
• 1x M.2 B Key, 2242/3042/3052 (PCIe x2, Support AI Module/NVMe Storage, PCIe x1 & USB 3.2 Gen1, Support 4G/5G)
• 1x M.2 B Key, 2242/3042/3052 (PCIe x2 /SATA, Support AI Module/NVMe/SATA Storage)
• 3x RS-232/422/485
• 6x USB 3.2 Gen 2 (10 Gbps)
• 8x DI + 8x DO with isolation
• 9 to 48VDC Wide Range Power Input Supporting AT/ATX Mode
• Wide Operating Temperature (-25°C to 60°C)
• TPM 2.0 Supported
